13.56MHz NXP family of MIFARE credentials
Overview
Genuine NXP MIFARE Classic credentials, fully compliant with ISO/IEC 14443 Type A; available with 1 kB and 4 kB memory and 7-byte or 4-byte identifiers.
Key Features
- Contactless transmission of data and energy supply
- Operating frequency of 13.56 MHz
- Data integrity of 16-bit CRC, parity, bit coding, bit counting
- Typical ticketing transaction time of < 100 ms (including backup management)
- Random ID support (7 Byte UID version)
- Operating distance up to 100 mm depending on reader configuration
- Data transfer of 106 kbit/s
- Anti-collision
- 7 Byte UID or 4 Byte NUID
- Mutual three-pass authentication (ISO/IEC DIS 9798-2)
- An individual set of two keys per sector to support multiapplication with key hierarchy
Typical applications
- Public transportation
- Access control
- Electronic toll collection
- Car parking
- School and campus cards
- Employee cards
- Internet cafés
- Loyalty
10A Series
ISO Card : Gloss White : PETF
Industry standard ISO card constructed with PETF outer layers providing extended temperature resistance, durability and a great surface for printing.
10C Series
Clamshell Card
A cost competitive card package, constructed with an ABS shell that provides durability in harsh environments.
10B Series
Key Fob : Black : ABS
A stylish Key Fob with a thickness of only 2.2mm. The internal circuitry is completely overmolded in ABS plastic making it very durable and fully sealed from moisture ingress.
